WickGrid™
Product Specifications
Product Brochure
More Information
WickGrid™
Built to Reinforce. Engineered to Drain. Proven to Perform.
WickGrid™ is a novel geogrid composite combining a high-stiffness, open-aperture polymeric geogrid with a unique non-woven geotextile possessing wicking properties in all directions. The wicking mechanism is primarily based on the proprietary microstructure and treatment of the non-woven geotextile component. WickGrid™ allows for structural stability while transporting water at zero gradient and thereby reducing pore pressure accumulation.
Patent is pending in Canada and USA.
Benefits of WickGrid™
- Designed to withstand freeze-thaw cycles and extreme weather, reducing frost heave damage and induced differential displacement.
- Offers reinforcement, confinement, separation, drainage, filtration, and wicking, all in one product.
- Increases bearing capacity, improves modulus and stabilizes low load bearing soils.
- Mechanically and chemically stable in aggressive environments.
- Use results in significant embodied carbon (EC) reduction, fostering sustainability.
Primary Applications
- Paved and unpaved roads over weak and saturated subgrades
- Railway embankments
- Oil platform access roads
- Mine haul roads
- Forestry and logging roads
- Coastal roads
- Parking lots
- Airport runways and taxiways
Features
- The wicking geotextile component of the WickGridTM possesses hydrophilic and forced wetting properties, facilitating high wet front movement and preventing water pooling.
- Manages and homogenizes the moisture content over peat and other very weak, saturated and variable subgrades.
- Exceptional performance even in unsaturated, zero-gradient conditions.
Request a Quote
We welcome the opportunity to work with you on your next infrastructure project. Send us a message, and our team will get back to you promptly.
Pre-Design Services
Titan specializes in pre-designs for 7 different applications. Our FREE pre-design service provides first-class customized design support helping to save you time on infrastructure, site development and geotechnical projects.
